Key takeaways
- 80 Hz is the standard starting crossover for most bookshelf and satellite speakers, and it is worth using even on larger towers that could technically run without one.
- Automatic room correction sometimes pushes a crossover above 120 Hz by mistaking boundary reinforcement for real bass extension, and that result is usually worth overriding back down manually.
- A test tone sweep through the crossover point should sound continuous. A dip or a doubled hump at that frequency means the number, or the subwoofer's level, still needs adjusting.
- Raising the crossover in 20 Hz steps, checking after each one, resolves strained or thin sounding dialogue caused by a crossover set too low for the main speakers.
- A boomy note that survives every crossover adjustment is very rarely a crossover problem at all, and is usually down to subwoofer placement, gain, or the room's own dimensions instead.
Your receiver’s setup menu is open on the line marked Crossover, or on some models LPF for LFE, and the number sitting there right now was chosen by whichever automatic calibration wizard ran last, or by nobody at all. Get this one setting wrong and every other calibration step downstream inherits the mistake.
Set too low, small speakers strain and distort on bass they were never built to reproduce. Set too high, the subwoofer takes over a range the main speakers could have handled cleanly, often creating the exact kind of boomy, one note bass that gets blamed on the subwoofer itself.
The subwoofer channel most receivers label LFE is standardised the same way across Dolby’s multichannel formats and DTS:X, so the crossover you choose here applies whether the source is a streaming service or a disc.
Before you touch the crossover menu
This takes 10 to 15 minutes and needs three things: access to the receiver’s speaker configuration menu, the size and rough bass extension of your main speakers, and ideally an SPL meter or phone app, though a good pair of ears will get you most of the way there.
Do this before running or re running any automatic room correction system such as Audyssey, YPAO, or Dirac Live, since a sensible starting point gives the automated system less work to correct and makes its result easier to sanity check afterward.
Soundbars complicate this slightly. Most fix their own internal crossover between the bar’s built in drivers and its external subwoofer, leaving only a coarse bass or subwoofer level adjustment for the user rather than a specific Hz figure to set. A full AV receiver, by contrast, exposes the actual frequency, which is one reason a receiver based system is generally easier to calibrate precisely than a soundbar and sub pairing.
Picking a starting frequency from your speaker size
Most bookshelf and satellite speakers, including compact designs like the ones in a Klipsch Flexus system, roll off somewhere between 60 and 100 Hz. Setting the crossover at 80 Hz, the long standing default recommended by THX and used on most calibration discs, hands the subwoofer everything below that point and asks the mains to do nothing they cannot already do cleanly.
Larger tower speakers that measure flat down to 40 or 50 Hz can technically run without a crossover at all, set to Large in the receiver’s menu. Many technicians, myself included, still cross even capable towers at 60 to 80 Hz anyway, since a tower working less hard at the bottom end distorts less everywhere else and integrates more smoothly with a subwoofer built for exactly that job.
A small satellite speaker crossed too low, at 40 Hz for example, gets asked to reproduce content it cannot without straining the driver and adding audible distortion, a common cause of harshness that gets mistaken for a speaker fault rather than a setup mistake.
Setting every channel to small and dialing in the number
On a typical receiver such as a Denon AVR-X1800H, the process is the same regardless of brand: open Speaker Configuration, set every channel that shares a subwoofer to Small, and enter the crossover frequency, usually adjustable in 10 Hz steps somewhere between 40 and 200 Hz, for each one.
Front, center, and surround channels rarely need different numbers from each other unless the speakers themselves are genuinely mismatched in size, a center channel from a larger family than the front pair, for instance. When in doubt, use the same crossover across every channel and let the subwoofer handle the shared workload evenly.
A recent job illustrates the one mistake this step catches: a client’s 5.1 system paired Klipsch Flexus surrounds with a 10 inch standalone subwoofer in a 4 by 5 metre living room. Every channel went to Small at 80 Hz in the receiver, verified afterward with a test tone sweep, but the subwoofer’s own crossover dial, which most standalone units include separately from the receiver’s setting, was still sitting at its maximum, effectively disengaged and passing everything through.
That is the correct pairing: one active crossover, set on the receiver, with the subwoofer’s own dial turned fully open so it is not filtering anything a second time. Leaving both crossovers active at different frequencies is a common, avoidable mistake that reintroduces exactly the kind of doubled, boomy bass a single correctly set crossover is supposed to prevent.
Letting room correction fine tune it, then checking its work
Automatic room correction systems measure your speakers with a calibration microphone and frequently override the crossover you just set, sometimes reasonably, sometimes not. Audyssey in particular will occasionally push a crossover unexpectedly high, 150 or even 200 Hz, if it detects boundary reinforcement it interprets as genuine bass extension.
Check the number it landed on for every channel after the sweep finishes. A crossover the automated system chose above 120 Hz for anything but a genuinely small satellite speaker is worth overriding back down manually to 80 or 100 Hz, since that kind of result is usually the microphone reading room gain rather than real speaker capability.
Write down the crossover number for each channel before running automatic room correction. Comparing it against what the system chooses afterward takes seconds and catches most misreads immediately.
Confirming the setting is correct by ear and with a test tone
Play a test tone sweep, built into most receivers’ setup menus, or from a calibration disc, from about 40 Hz up through 200 Hz, and listen at the crossover point specifically. A correctly set crossover sounds continuous through that region.
A wrong one produces either a small dip, where neither the speaker nor the subwoofer is fully covering that frequency, or a doubled, slightly boomy hump where both are. With real content, a bass heavy scene should sound like one continuous source rather than an obviously separate, boxy subwoofer sound sitting underneath a thinner main speaker sound.
That seam being audible is the clearest sign the crossover number, or the subwoofer’s own level relative to the other channels, still needs adjustment.
Check the crossover point at more than one volume before calling it finished. A seam that is inaudible at a moderate listening level, around 75 dB, can become obvious once the volume climbs during an action scene and the subwoofer’s output compresses slightly under load, a limitation particular to smaller sealed designs such as an SVS SB-1000 Pro pushed hard.
Symptoms that mean the crossover is still wrong
A persistent boom on specific notes after all this usually is not the crossover at all, and is worth working through the causes in fixing boomy bass in a small room instead, particularly subwoofer placement and gain.
Thin, strained sounding dialogue or effects, by contrast, often means the crossover is still set too low for what the main speakers can actually deliver. Raise it in 20 Hz steps, checking each time, until the strain disappears without noticeably increasing the workload asked of the subwoofer.
Subwoofer placement and driver size both affect how comfortably it can absorb that extra range once you do, so a crossover fix that does not fully settle is sometimes really a placement question in disguise.
- Set every relevant channel to Small before dialing in a number
- Start at 80 Hz for compact speakers, 60 Hz for capable towers
- Run automatic room correction, then check the crossover it chose
- Sweep a test tone through the crossover point and listen for a dip or hump
- Adjust in 20 Hz steps and recheck rather than guessing a large jump
Questions readers ask about this
Start at 80 Hz for bookshelf, satellite, and most compact tower speakers, since that is the long standing default used by THX and most calibration discs. Larger towers that measure flat down to 40 or 50 Hz can run without a crossover, though many installers cross them at 60 to 80 Hz anyway for smoother integration with the subwoofer.
Small, in almost every case, even for capable tower speakers, paired with a crossover around 60 to 80 Hz. A speaker working less hard at the very bottom of its range distorts less everywhere else, and handing that range to a dedicated subwoofer nearly always sounds cleaner than letting the main speaker cover it alone.
Not always. Systems such as Audyssey occasionally set a crossover above 120 Hz for a speaker that is not genuinely that small, usually because the measurement microphone picked up boundary reinforcement and read it as real bass extension. Checking the final number against your speaker's actual size after the sweep finishes is worth the extra two minutes.
The speaker gets asked to reproduce bass below what its driver can move cleanly, which shows up as strain, distortion, or a thin, harsh quality on bass heavy scenes. Raising the crossover in 20 Hz steps until that strain disappears, without overloading the subwoofer, usually resolves it within one or two adjustments.
Most receivers allow it, and it helps when speakers genuinely differ in size, a larger center channel paired with smaller surrounds, for example. Where every speaker in a system is a similar size, using the same crossover across every channel is simpler and rarely costs anything in sound quality.
